Log Debarker

Category: Log Debarker

Date: 2021-02-19 02:20:49

Overview: 厨房垃圾处理设备是指安置在厨房的，将厨余垃圾进行初步处理的设备。常规处理设备为食···

Product Details | PRODUCT DETAILS

The drum wood chipper is mainly consist by 2 parts: peeling main machine body and the electric control system. Usually there is no need to equip the feeding conveyor system, end user will need to use the fork grab or forklift to grab the logs and put it onto the machine.

The function of the log debarker is to get rid the outside barks from the logs, after the barks off, the logs will be chipped by the wood chipper and achieve clean chips, which is widely use for paper making industry, such as the paper pulp making.

Model	XT-SP800	XTSP-900	XTSP-1000	XTSP-12000	XTSP-1400
Type	Single roller	Single roller	Single roller	Single roller	Single roller
Peeling roller diameter	800mm	900mm	1000mm	1200mm	1400mm
Main motor	55KW	75KW	90KW	110KW	132KW
Motor of bottom belt	4KW	4KW	5.5KW	5.5KW	7.5KW
Production capacity	20-25Ton/Hour	25-30Ton/Hour	30-35Ton/Hour	35-40Ton/Hour	40-45Ton/Hour
Debarking rate	more than 90%	more than 90%	more than 92%	more than 92%	more than 92%
Maximum log diameter	350mm	400mm	450mm	500mm	600mm
Machine overall size	1650240012000mm	1750240012000mm	1850240012000mm	2050240012000mm	2250240012000mm
Machine weight	15.2Ton	17.5Ton	19.5Ton	22Ton	24Ton
Electric control cabinet	Included	Included	Included	Included	Included
