Sawdust Crusher

Category: Sawdust Crusher

Date: 2021-02-19 02:20:53

Overview: 厨房垃圾处理设备是指安置在厨房的，将厨余垃圾进行初步处理的设备。常规处理设备为食···

Product Details | PRODUCT DETAILS

The sawdust crusher is mainly consist by 5 parts: feeding part, crushing main body, discharge part, cyclone dust remover and the electric control system.

The machine is main for crushing wood chips, nut shells into sawdust with size 4mm-10mm, it is widely use in biomass pellet industry, animal breeding farms (animal shelters), mushroom cultivation plants, density board production plants...etc.

Special point: the machine is for fine crushing, so its production capacity will not be as large as the wood chipper or the biomass shredder. For the capacity and model options, there will be as the follows:

Model	XTH-55	XTH-90	XTH-110	XTH-160	XTH-220
Rotor diameter	650mm	800mm	800mm	800mm	1000mm
Hammer blades installed	48pcs	72pcs	96pcs	144pcs	168pcs
Main motor power	55KW	90KW	110KW	160KW	220KW
Fan blower power	5.5KW	7.5KW	11KW	15KW	22KW
Running speed	1450r/min	1450r/min	1450r/min	1450r/min	1450r/min
Production capacity	1-2Ton/Hour	2-3Ton/Hour	3-4Ton/Hour	4-5Ton/Hour	5-6Ton/Hou
Finished sawdust size	4mm-10mm	4mm-10mm	4mm-10mm	4mm-10mm	4mm-10mm
Cyclone	Included	Included	Included	Included	Included
Dust remover	Included	Included	Included	Included	Included
Electric control cabinet	Included	Included	Included	Included	Included
Feeding conveyor	4m length	4m length	5m length	5m length	5m length
Machine main body size	1650x1000x1250mm	2280x1200x1400mm	2400x1300x1500mm	26500x1500x1650mm	3050x1900x2100mm
Air lock	Included	Included	Included	Included	Included
Machine weight	3.2Ton	4.4Ton	5.4Ton	6.5Ton	7.8Ton
